DS1013 Debugger 10-Pin Male Box Header Connector
The DS1013 Debugger 10-Pin Male Box Header Connector is a standard 2×5 (10-pin) through-hole box header used for connecting DS1013, SWD, and JTAG debuggers to embedded development boards. It enables reliable programming, debugging, and real-time monitoring of ARM Cortex-based microcontrollers during application development.
Featuring a 2.54 mm pin pitch and a polarized box header design, the connector ensures correct cable orientation and secure attachment, minimizing connection errors during debugging sessions.
Its robust through-hole construction provides excellent mechanical strength, making it suitable for development boards, evaluation kits, industrial controllers, and custom embedded hardware. The connector is widely used with STM32, ARM Cortex-M microcontrollers, and other embedded platforms supporting SWD or JTAG debugging.
Applications
- STM32 Development Boards
- ARM Cortex Microcontrollers
- DS1013 Debugger Interface
- SWD Debugging
- JTAG Programming
- Firmware Development
- Embedded Systems
- In-System Programming (ISP)
- Industrial Control Systems
- PCB Prototyping
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | DS1013 Debugger Male Box Header Connector |
| Device Type | 2×5 (10-Pin) Male Box Header |
| Number of Pins | 10 |
| Pin Configuration | 2 Rows × 5 Pins |
| Pin Pitch | 2.54 mm |
| Mounting Type | Through-Hole (THT) |
| Connector Style | Polarized Box Header |
| Compatible Interfaces | SWD, JTAG |
| Material | Plastic Housing with Metal Contacts |
| Applications | Embedded Systems, Programming & Debugging |
